CS01 Series 2.54mm(.100) Dual Row Multiple Shunts

    • CS01 Series 2.54mm(.100) Dual Row Multiple Shunts

    • Tel:0510-85578880


◎ Rated current and voltage : 3A 250V AC
◎ Dielectric Withstanding Voltage : 1000V AC for one minute
◎ Contact Resistance : <20mΩ
◎ Insulation Resistance : >1000MΩ
◎ Operating Temperature : -40℃~ 105℃
◎ RoHS Compliant

CIRCUITS 02 CIRCUITS
Plating Code 2= Gold Flash Plated over 50μ” Nickel


Mate Parts CH31 Series 2.54mm(.100 :
CH31 Series 2.54mm(.100 :
CH34 Series 2.54mm(.100 :
CH85 Series 2.54mm(.100 :
CH81 Series 2.54mm(.100 :
CH81 Series 2.54mm(.100 :
CH84 Series 2.54mm(.100 :
CH84 Series 2.54mm(.100 :
CH96 Series 2.54mm(.100 :
CH96 Series 2.54mm(.100 :


CIRCUITS 02 CIRCUITS
Plating Code 2= Gold Flash Plated over 50μ” Nickel
Mate Parts CH31 Series 2.54mm(.100
CH31 Series 2.54mm(.100
CH34 Series 2.54mm(.100
CH85 Series 2.54mm(.100
CH81 Series 2.54mm(.100
CH81 Series 2.54mm(.100
CH84 Series 2.54mm(.100
CH84 Series 2.54mm(.100
CH96 Series 2.54mm(.100
CH96 Series 2.54mm(.100
